49
8.3 Sensor without terminal replacement
Sensor replacement guidelines
Cut off the damaged head of sensor.
Strip off the sensor wiring.
Take out a new sensor to cut the head of sensor.
(Spare parts code：11201007000795) Its technical
specifications apply to all MIDEA refrigerators.
Strip off the head of the sensor and connect it.
Wrap the two wires together with insulation tape.
Wrap the two wires together.
