High Temperature Hydro Module
32 202003
Midea
VR High Temperature Hydro Module
To enable the group control function, you need to set the DIP switch on the main board as follows: for the master hydraulic
module, turn digit 11; for the slave hydraulic module, turn digit 10:
To enable the group control function, you need to set the DIP switch on the main board as follows: for the master hydraulic
module, turn digit 11; for the slave hydraulic module, turn digit 10:
The master unit must be connected to a wired controller. The wired controller is used to set the desired water
The slave unit can be connected to or not connected to a wired controller. The wired controller of the slave unit
provides the query function only.
The pump is controlled by the master unit. The temperature sensor of the water tank is connected to the master
The wired controller connected to the master unit is used to set the desired water tank temperature.
Notes for installers and service engineers
