VR High Temperature Hydro Module
For example:
The time is 8:00 and temperature is 60℃. If PRESET TEMP. is set as follows, the hydraulic module will operate according to the
following curve.
When the multiple set point function is enabled, the PRESET TEMP. function is valid to space0 only.
If the hydraulic module is powered off, the preset temperature at the current time is invalid. The hydraulic
module will be started at the time point where the next preset temperature is set.
When the timer function is valid, if you move the cursor to PRESET TEMP. and press the OK key, the following
The preset temperature is only valid for the water outlet temperature control of heat mode. If ROOM TEMP. is
set to YES on the wired controller, the following information is displayed:
Notes for installers and service engineers
