Midea SMK-D140HHN1-3

High Temperature Hydro Module
50 202003
Midea
VR High Temperature Hydro Module
For example: You have set the parameter about the DHW PUMP (See ''FOR SERVICEMAN'‘ > ''DHW MODE
SETTING'' on ''Engineering Data''). PUMP RUNNING TIME is 30 minutes.
Set as follows:
No.
START
1
06:00
2
07:00
3
8:00
4
09:00
Important Notes
 If DHW MODE=NON, choose MENU > DOMESTIC HOT WATER. Press OK. The following interface is displayed.

If DISINFECT MODE=NON on the FOR SERVICEMAN interface, choose MENU > DOMESTIC HOT WATER >
DOMESTIC HOT WATER. Press OK. The following interface is displayed.

If DISINFECT MODE=NON on the FOR SERVICEMAN interface, choose MENU > DOMESTIC HOT WATER >
DOMESTIC HOT WATER. Press OK. The following interface is displayed.

If DHW PUMP RUNNING TIME=NON, choose MENU > DOMESTIC HOT WATER > DHW PUMP. Press OK. The
following interface is displayed.
Notes for installers and service engineers

