Midea SMK-D140HHN1-3

High Temperature Hydro Module
202003 75
Service
Manual
19
MULTIPLE
SET POINT
SETTING
multiple set point 1
Multiple set point 1 on/off:
0 = OFF, 1 = YES
0
0
1
1
/
20
multiple set point 2
Multiple set point 2 on/off:
0 = OFF, 1 = YES
0
0
1
1
/
21
HOLIDAY
AWAY
SETTING
TwoutS_H.A_H
Water outlet temperature
of holiday mode
25
28
80
1
°C
22
TtankS_H.A_DHW
Water tank temperature of
holiday mode
40
25
80
1
°C
23
HEAT
RECOVERY
MODE
SRTTING
HEAT RECOVERY
Heat recovery mode
on/off: 0 = NON， 1 =
YES
1
0
1
1
/
24
Ttank_recovery_max
Max. heat recovery water
tank temperature
70
45
80
1
°C
25
POWER
INPUT
LIMITATION
POWER INPUT
LIMITATION
Sets input power limitation
gear: 0 = Not limited, 1 =
Gear 1, 2 = Gear 2, 3 =
Gear 3
0
0
3
1
/
26
SMART GRID
SMART GRID
Sets smart grid on/off: 0 =
NON， 1 = YES
0
0
1
1
/
27
Ttank_smartgrid_max
Sets the highest water
tank temperature of the
smart grid
70
45
80
1
°C
28
HYDRO BOX
ADDERSSING
HYDRO BOX
ADDERSSING
Sets hydraulic module
address
0
0
63
1
/
29
TEST RUN
VACUUM PUMPING
Sets vacuumizing mode
on/off
0
0
1
1
/
30
CIRCULATED PUMP
RUNNING
Sets external water pump
on/off
0
0
1
1
/
31
DHW PUMP
RUNNING
Sets water tank and pump
on/off
0
0
1
1
/
