Midea US-FC70-DS12DSH/C0401E

Service manual forWash and Dry Combo producf
Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－
46
－
28
Internal
Wire Assembly (supplementary)
1
302430760174
29
W
ater Inlet Hose Assembly1
2
302730700026
30
W
ater Inlet Hose Assembly
1
302730760019
31
Disp
enser Subassembly
1
301130860130
32
Disp
enser
1
301130600571
33
Dr
awer Handle And Printing
1
301130761065
34
Cycle Select Knob
1
301130960016
35
LED Display Panel
1
301130761070
36
Control Panel Assembly
1
301130761068
37
buttons
1
301130800818
38
PCB
1
301330760335
39
Water Inlet Valve(302430760098 one enter three
t )
1
302430760098
40
W
ater Inlet Valve(302430760039 one enter one out )
1
302430760039
41
Front Left Counterweight
1
302930800037
42
Front Right Counterweight
1
302930800035
43
Rear Counterweight
1
302930800036
44
Door Gasket
1
302730760006
45
Suspension Spring
1
302930700010
46
Front Tub Assembly
1
301130700366
47
Spi
der Assembly
1
302930860016
48
Baffle
3
301130700138
49
Rear
Counterweight
1
302930800036
50
Belt
1
302730660008
51
Pul
ley
1
302930700028
52
Rear
Tub Assembly
1
301130800141
53
Heater
1
302430760040
54
Heater Support
1
301130600163
55
Drain Pump
1
302430760035
56
Tub Drain Hose Assembly
1
302730500049
57
Dam
per
2
302530900001
58
Dam
per Pin
2
301130600001
59
Inverter
Motor
1
302430760172
60
Motor
Bracket
1
302930600013
61
Spec
ial Bolt
1
302501150001
62
Tunnel Seal
1
302730700012
63
Reflection Plate
1
301230800077
64
Tunnel Base
1
301230800084
65
Clamp Piece
1
302930700040
66
Felt
1
301230800083
67
T
emperature Sensor, drum – out (302411600802)
1
302411600802
68
Man
ual Temperature Sensor
2
302430700102
69
T
emperature Sensor, drum – in (302430700042)
1
302430700042
70
Fan
Flange Assembly
1
302930760025
71
Coo
ling Pipe
1
302730760029
