Midea US-FC70-DS12DSH/C0401E

Service manual forWash and Dry Combo producf
Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－
45
－
7. SPARE PARTS
No.
Part Name
Quantity
Part code
1
Top Cover Assembly
1
301130761067
2
Rear Cover
1
301230700086
3
Power Cord
1
302430760092
4
Bolt
4
302500200084
5
Drain Hose
1
302730600054
6
Drain Hose Catch
1
301130600275
7
Hole Cover
4
301130650057
8
Water Level Switch
1
302434270063
9
Water Level Switch Support
1
301230760199
10
Door Lock
1
302430860062
11
Lint Filter Door
1
301130761064
12
Service Plate Box
1
301130761041
13
Door Gasket Spring Clip Spring
1
302930700037
14
Door
Hinge Assemble Bracket
1
301230600063
15
Front
Panel
1
301230760279
16
Adjust
able Foot Assembly
4
302930700025
17
Cab
inet Assembly
1
301230760295
18
Front
Panel Pin
2
301130750001
19
Top Bracket
1
301230660127
20
Door Subassembly
1
—
20.1
Door Glass
1
303630960001
20.2
Inner Ring
1
301130761040
20.3
Outer Frame Assembly
1
301130860705
20.4
Door Plunger
1
302930600035
20.5
Door
Hinge
1
302930800033
21
Spri
ng Support
2
301130600277
22
W
ater Inlet Hose Assembly (301130760437 cold
w
ater)
1
301130760437
23
W
ater Inlet Hose Assembly (301130760438 hot
w
ater)
1
301130760438
24
Electric Filter Support
1
301130760720
25
Capacitor
1
302430760100
26
Electric Filter
1
302430860035
27
Internal Wire Assembly
1
302430760165
