Midea V6R Series

V6R VRF 50/60Hz
23
Part 2
-
Outdoor Unit Engineering Data
16-20HP
Table 2-1.2: 16-20HP specifications
HP
14
16
18
20
Model name
MV6-
R400WV2GN1
MV6-
R450WV2GN1
MV6-
R500WV2GN1
MV6-
R560WV2GN1
Power supply
V/N/H
z
380-415/3/50(60)
Cooling
1
Capacity
kW
40
45
50
56
Power input
kW
9.83
12.00
13.81
17.39
EER
4.07
3.75
3.62
3.22
Heating
2
(Rated)
Capacity
kW
40
45
50
56
Power input
kW
8.26
9.78
11.90
14.77
COP
4.84
4.60
4.20
3.79
Heating
2
(Max)
Capacity
kW
45
50
56
63
Power input
kW
9.78
12.26
14.77
18.33
COP
4.60
4.08
3.79
3.44
Connected
indoor unit
Total capacity
50-200% of outdoor unit capacity
3
Maximum quantity
64
64
64
64
Compressor
Type
DC inverter
DC inverter
Quantity
1
Oil type
FV68H
Start-up method
Soft start
Fan
Type
Propeller
Motor type
DC
Quantity
2
Motor output
kW
0.92×2
0.92×2
0.92×2
0.92×2
Static pressure
Pa
0,20,40,60,80(Selectable)
Air flow rate
m
3
/h
14000
14900
15800
15800
Drive type
Direct
Refrigerant
Type
R410A
Factory charge
kg
10
10
10
10
Pipe
connections
4
Liquid pipe
mm
Φ15.9
Φ15.9
Φ15.9
Φ15.9
Low pressure gas
pipe
mm
Φ28.6
Φ28.6
Φ28.6
Φ28.6
High pressure gas
pipe
mm
Φ22.2
Φ22.2
Φ22.2
Φ22.2
Sound pressure level
5
dB(A)
61
64
65
65
Sound power level
5
dB(A)
81
88
88
88
Net dimensions (W×H×D)
mm
1340×1635×825
1340×1635×825
1340×1635×825
1340×1635×825
Packed dimensions (W×H×D)
mm
1405×1805×910
1405×1805×910
1405×1805×910
1405×1805×910
Net weight
kg
300
300
300
300
Gross weight
kg
325
325
325
325
Ambient temp.
operation range
Cooling
6
o
C(DB)
-15 ~ 52
Heating
o
C(WB)
-25 ~ 19
Domestic hot water
o
C(DB)
-20 ~ 43
Notes:
1. Indoor air temperature 27°C DB, 19°C WB; outdoor air temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor air temperature 20°C DB; outdoor air temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Refer to table 1-5.1: Indoor and outdoor unit combination ratio limitations in Part 1.
4. Diameters given are those of the unit's stop valve.
5. Sound pressure level is measured at a position 1m in front of the unit and 1.3m above the floor in a semi-anechoic chamber.
6. -15°C to -5°C low temperature cooling operation is just available for MS01.
