V6R Series Engineering Data Book
22-26HP
Table 2-1.3: 22-26HP specifications
HP
22
24
26
Model name
MV6-R615WV2GN1
MV6-R680WV2GN1
MV6-R735WV2GN1
Combination type
10HP+12HP
10HP+14HP
12HP+14HP
Power supply
V/N/Hz
380-415/3/50(60)
Cooling
1
Capacity
kW
61.5
68
73.5
Power input
kW
15.82
17.01
18.46
EER
3.89
4.00
3.98
Heating
2
(Rated)
Capacity
kW
61.5
68
73.5
Power input
kW
12.03
13.72
14.83
COP
5.11
4.96
4.96
Heating
2
(Max)
Capacity
kW
69.00
76.50
82.5
Power input
kW
16.60
16.90
19.27
COP
4.16
4.53
4.28
Connected indoor
unit
Total capacity
50-200% of outdoor unit capacity
3
Maximum quantity
64
64
64
Compressor
Type
DC inverter
Quantity
2
Oil type
FV68H
Start-up method
Soft start
Fan
Type
Propeller
Motor type
DC
Quantity
2
2
3
Motor output
kW
0.92×2
0.92×3
0.92×3
Static pressure
Pa
0,20,40,60,80(Selectable)
Air flow rate
m
3
/h
19500
23500
24000
Drive type
Direct
Refrigerant
Type
R410A
Factory charge
kg
16
18
18
Pipe connections
4
Liquid pipe
mm
Φ15.9
Φ15.9
Φ19.1
Low pressure gas
pipe
mm
Φ28.6
Φ34.9
Φ34.9
High pressure gas
pipe
mm
Φ28.6
Φ28.6
Φ28.6
Sound pressure level
5
dB(A)
62
63
64
Sound power level
5
dB(A)
83
83
84
Net dimensions (W×H×D)
mm
(990×1635×790)×2
990×1635×790+
1340×1635×825
990×1635×790+
1340×1635×825
Packed dimensions (W×H×D)
mm
(1090×1805×860)×2
1090×1805×860+
1405×1805×910
1090×1805×860+
1405×1805×910
Net weight
kg
232×2
232+300
232+300
Gross weight
kg
248×2
248+325
248+325
Ambient temp.
operation range
Cooling
6
o
C(DB)
-15 ~ 52
Heating
o
C(WB)
-25 ~ 19
Domestic hot water
o
C(DB)
-20 ~ 43
Notes:
1. Indoor air temperature 27°C DB, 19°C WB; outdoor air temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor air temperature 20°C DB; outdoor air temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Refer to table 1-5.1: Indoor and outdoor unit combination ratio limitations in Part 1.
4. Diameters given are those for the pipe connecting the outdoor unit combination to the first indoor branch joint for systems with total equivalent liquid piping
lengths of less than 90m. For systems with total equivalent liquid piping lengths of 90m or longer, please refer to Part 3 “System Design and Installation” for
connection piping diameters.
5. Sound pressure level is measured at a position 1m in front of the unit and 1.3m above the floor in a semi-anechoic chamber.
6. -15°C to -5°C low temperature cooling operation is just available for MS01.
