Midea V6R Series

V6R VRF 50/60Hz
25
Part 2
-
Outdoor Unit Engineering Data
28-32HP
Table 2-1.4: 28-32HP specifications
HP
28
30
32
Model name
MV6-R785WV2GN1
MV6-R835WV2GN1
MV6-R900WV2GN1
Combination type
12HP+16HP
12HP+18HP
16HP+16HP
Power supply
V/N/Hz
380-415/3/50(60)
Cooling
1
Capacity
kW
78.5
83.5
90
Power input
kW
20.64
22.45
24.00
EER
3.80
3.72
3.75
Heating
2
(Rated)
Capacity
kW
78.5
83.5
90
Power input
kW
16.35
18.47
19.57
COP
4.80
4.52
4.60
Heating
2
(Max)
Capacity
kW
87.5
93.5
100
Power input
kW
21.74
24.25
24.52
COP
4.02
3.86
4.08
Connected
indoor unit
Total capacity
50-200% of outdoor unit capacity
3
Maximum quantity
64
64
64
Compressor
Type
DC inverter
Quantity
2
Oil type
FV68H
Start-up method
Soft start
Fan
Type
Propeller
Motor type
DC
Quantity
3
3
4
Motor output
kW
0.92×3
0.92×3
0.92×4
Static pressure
Pa
0,20,40,60,80(Selectable)
Air flow rate
m
3
/h
24900
25800
29800
Drive type
Direct
Refrigerant
Type
R410A
Factory charge
kg
18
18
20
Pipe
connections
4
Liquid pipe
mm
Φ19.1
Φ19.1
Φ19.1
Low pressure gas pipe
mm
Φ34.9
Φ34.9
Φ34.9
High pressure gas pipe
mm
Φ28.6
Φ28.6
Φ28.6
Sound pressure level
5
dB(A)
65
66
67
Sound power level
5
dB(A)
89
89
91
Net dimensions (W×H×D)
mm
990×1635×790+
1340×1635×825
990×1635×790+
1340×1635×825
(1340×1635×825)×2
Packed dimensions (W×H×D)
mm
1090×1805×860+
1405×1805×910
1090×1805×860+
1405×1805×910
(1405×1805×910)×2
Net weight
kg
232+300
232+300
300×2
Gross weight
kg
248+325
248+325
325×2
Ambient temp.
operation range
Cooling
6
o
C(DB)
-15 ~ 52
Heating
o
C(WB)
-25 ~ 19
Domestic hot water
o
C(DB)
-20 ~ 43
Notes:
1. Indoor air temperature 27°C DB, 19°C WB; outdoor air temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor air temperature 20°C DB; outdoor air temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Refer to table 1-5.1: Indoor and outdoor unit combination ratio limitations in Part 1.
4. Diameters given are those for the pipe connecting the outdoor unit combination to the first indoor branch joint for systems with total equivalent liquid piping
lengths of less than 90m. For systems with total equivalent liquid piping lengths of 90m or longer, please refer to Part 3 “System Design and Installation” for
connection piping diameters.
5. Sound pressure level is measured at a position 1m in front of the unit and 1.3m above the floor in a semi-anechoic chamber.
6. -15°C to -5°C low temperature cooling operation is just available for MS01.
