V6R Series Engineering Data Book
34-38HP
Table 2-1.5: 34-38HP specifications
HP
34
36
38
Model name
MV6-R950WV2GN1
MV6-R1000WV2GN1
MV6-R1060WV2GN1
Combination type
16HP+18HP
18HP+18HP
18HP+20HP
Power supply
V/N/Hz
380-415/3/50(60)
Cooling
1
Capacity
kW
95
100
106
Power input
kW
25.81
27.62
31.20
EER
3.68
3.62
3.40
Heating
2
(Rated)
Capacity
kW
95
100
106
Power input
kW
21.69
23.81
26.67
COP
4.38
4.20
3.97
Heating
2
(Max)
Capacity
kW
106
112
119
Power input
kW
27.03
29.53
33.09
COP
3.92
3.79
3.60
Connected indoor
unit
Total capacity
50-200% of outdoor unit capacity
3
Maximum quantity
64
64
64
Compressor
Type
DC inverter
Quantity
2
Oil type
FV68H
Start-up method
Soft start
Fan
Type
Propeller
Motor type
DC
Quantity
4
Motor output
kW
0.92×4
0.92×4
0.92×4
Static pressure
Pa
0,20,40,60,80(Selectable)
Air flow rate
m
3
/h
30700
31600
31600
Drive type
Direct
Refrigerant
Type
R410A
Factory charge
kg
20
20
20
Pipe connections
4
Liquid pipe
mm
Φ19.1
Φ19.1
Φ19.1
Low pressure gas
pipe
mm
Φ34.9
Φ34.9
Φ41.3
High pressure gas
pipe
mm
Φ28.6
Φ28.6
Φ34.9
Sound pressure level
5
dB(A)
68
68
68
Sound power level
5
dB(A)
91
91
91
Net dimensions (W×H×D)
mm
(1340×1635×825)×2
(1340×1635×825)×2
(1340×1635×825)×2
Packed dimensions (W×H×D)
mm
(1405×1805×910)×2
(1405×1805×910)×2
(1405×1805×910)×2
Net weight
kg
300×2
300×2
300×2
Gross weight
kg
325×2
325×2
325×2
Ambient temp.
operation range
Cooling
6
o
C(DB)
-15 ~ 52
Heating
o
C(WB)
-25 ~ 19
Domestic hot water
o
C(DB)
-20 ~ 43
Notes:
1. Indoor air temperature 27°C DB, 19°C WB; outdoor air temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor air temperature 20°C DB; outdoor air temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Refer to table 1-5.1: Indoor and outdoor unit combination ratio limitations in Part 1.
4. Diameters given are those for the pipe connecting the outdoor unit combination to the first indoor branch joint for systems with total equivalent liquid piping
lengths of less than 90m. For systems with total equivalent liquid piping lengths of 90m or longer, please refer to Part 3 “System Design and Installation” for
connection piping diameters.
5. Sound pressure level is measured at a position 1m in front of the unit and 1.3m above the floor in a semi-anechoic chamber.
6. -15°C to -5°C low temperature cooling operation is just available for MS01.
