V6R Series Engineering Data Book
58-60HP
Table 2-1.9: 58-60HP specifications
HP
58
60
Model name
MV6-R1620WV2GN1
MV6-R1680WV2GN1
Combination type
18HP+20HP+20HP
20HP+20HP+20HP
Power supply
V/N/Hz
380-415/3/50(60)
Cooling
1
Capacity
kW
162
168
Power input
kW
48.59
52.17
EER
3.33
3.22
Heating
2
(Rated)
Capacity
kW
162
168
Power input
kW
41.44
44.30
COP
3.91
3.79
Heating
2
(Max)
Capacity
kW
182
189
Power input
kW
51.42
54.98
COP
3.54
3.44
Connected indoor unit
Total capacity
50-200% of outdoor unit capacity
Maximum quantity
64
64
Compressor
Type
DC inverter
Quantity
3
Oil type
FV68H
Start-up method
Soft start
Fan
Type
Propeller
Motor type
DC
Quantity
6
6
Motor output
kW
0.92×6
0.92×6
Static pressure
Pa
0,20,40,60,80(Selectable)
Air flow rate
m
3
/h
47400
47400
Drive type
Direct
Refrigerant
Type
R410A
Factory charge
kg
30
30
Pipe connections
3
Liquid pipe
mm
Φ19.1
Φ19.1
Low pressure gas pipe
mm
Φ41.3
Φ41.3
High pressure gas pipe
mm
Φ34.9
Φ34.9
Sound pressure level
4
dB(A)
70
70
Sound power level
4
dB(A)
93
93
Net dimensions (W×H×D)
mm
(1340×1635×825)×3
(1340×1635×825)×3
Packed dimensions (W×H×D)
mm
(1405×1805×910)×3
(1405×1805×910)×3
Net weight
kg
300×3
300×3
Gross weight
kg
325×3
325×3
Ambient temp. operation
range
Cooling
o
C(DB)
-15 ~ 52
Heating
o
C(WB)
-25 ~ 19
Domestic hot water
o
C(DB)
-20 ~ 43
Notes:
1. Indoor air temperature 27°C DB, 19°C WB; outdoor air temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor air temperature 20°C DB; outdoor air temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Refer to table 1-5.1: Indoor and outdoor unit combination ratio limitations in Part 1.
4. Diameters given are those for the pipe connecting the outdoor unit combination to the first indoor branch joint for systems with total equivalent liquid piping
lengths of less than 90m. For systems with total equivalent liquid piping lengths of 90m or longer, please refer to Part 3 “System Design and Installation” for
connection piping diameters.
5. Sound pressure level is measured at a position 1m in front of the unit and 1.3m above the floor in a semi-anechoic chamber.
6. -15°C to -5°C low temperature cooling operation is just available for MS01.
