Midea V6R Series

V6R VRF 50/60Hz
31
Part 2
-
Outdoor Unit Engineering Data
1.2 Mode Selection Box
MS01/N1-D / MS04/N1-D / MS06/N1-D
Table 2-1.10: MS01/N1-D, MS04/N1-D, MS06/N1-D specifications
Model name
MS01/N1-D
1
MS04/N1-D
MS06/N1-D
Power supply
V/ph/Hz
220-240/1/50(60)
Max. number of indoor unit groups
1
4
6
Max. number of units per group
8
5
5
Max. number of downstream indoor units
8
20
30
Max. capacity of each group of indoor
units
kW
32
16
16
Total capacity of downstream indoor
units
kW
32
49
63
Pipe connections
to ODU
Liquid pipe
mm
∅9.53/∅12.7
∅9.53/∅12.7/∅15.9/∅19.05
∅9.53/∅12.7/∅15.9/∅19.05
Low pressure gas
pipe
mm
∅15.9/∅19.1/∅22.2
∅19.1/∅22.2/∅28.6
∅19.1/∅22.2/∅28.6
High pressure gas
pipe
mm
∅12.7/∅15.9/∅19.1
∅15.9/∅19.1/∅22.2/∅28.6
∅15.9/∅19.1/∅22.2/∅28.6
Pipe connections
to IDU
Liquid pipe
mm
∅6.35/∅9.53
∅6.35/∅9.53
∅6.35/∅9.53
Gas pipe
mm
∅12.7/∅15.9
∅12.7/∅15.9
∅12.7/∅15.9
Sound pressure level
2
dB(A)
40
44
45
Sound power level
2
dB(A)
60
63
65
Net dimensions (W×H×D)
mm
440×195×296
668×250×574
668×250×574
Packed dimensions (W×H×D)
mm
740×275×405
1020×390×850
1020×390×850
Net weight
kg
10.5
33
36
Gross weight
kg
14
58
61
Notes:
1. MS01 is for low temperature cooling operation and leakage detection.
2. The sound level is measured at a position 1m below the MS box in a semi-anechoic chamber whilst the MS box is switching mode. MS box should not be
installed in locations with low-noise requirements.
