V6R VRF 50/60Hz
32
Midea
V6R Series Engineering Data Book
MS08/N1-D / MS10/N1-D / MS12/N1-D
Table 2-1.11: MS08/N1-D, MS10/N1-D, MS12/N1-D specifications
Model name
MS08/N1-D
MS10/N1-D
MS12/N1-D
Power supply
V/ph/Hz
220-240/1/50(60)
Max. number of indoor unit groups
8
10
12
Max. number of units per group
5
5
5
Max. number of downstream indoor units
40
47
47
Max. capacity of each group of
indoor units
kW
16
16
16
Total capacity of downstream
indoor units
kW
85
85
85
Pipe connections
to ODU
Liquid pipe
mm
12.7/15.9/19.1/22.2
12.7/15.9/19.1/22.2
12.7/15.9/19.1/22.2
Low pressure gas
pipe
mm
22.2/28.6/34.9
22.2/28.6/34.9
22.2/28.6/34.9
High pressure gas
pipe
mm
19.1/22.2/28.6
19.1/22.2/28.6
19.1/22.2/28.6
Pipe connections
to IDU
Liquid pipe
mm
6.35/9.53
6.35/9.53
6.35/9.53
Gas pipe
mm
12.7/15.9
12.7/15.9
12.7/15.9
Sound pressure level
1
dB(A)
47
47
47
Sound power level
1
dB(A)
65
65
65
Net dimensions (W×H×D)
mm
974×250×574
974×250×574
974×250×574
Packed dimensions (W×H×D)
mm
1320×390×850
1320×390×850
1320×390×850
Net weight
kg
48
51
54
Gross weight
kg
79
82
85
Notes:
1. The sound level is measured at a position 1m below the MS box in a semi-anechoic chamber whilst the MS box is switching mode. MS box should not be
installed in locations with low-noise requirements.
