Midea V6R Series

V6R VRF 50/60Hz
37
Part 2
-
Outdoor Unit Engineering Data
2.3 Mode Selection Box
MS01
Figure 2-2.8: Ceiling-suspended type MS01 dimensions (unit: mm)
Notes :
1. MS01 can be ceiling-supended installed and wall-mounted installed.
2. MS01 is for low temperature cooling operation and leakage detection.
Figure 2-2.9: Wall-mounted type MS01 dimensions (unit: mm)
Notes :
1. MS01 can be ceiling-supended installed and wall-mounted installed.
2. Low temperature cooling operation and leakage detection function are available in MS01.
440
95
483
519
654
172
296
195
484
484
519
654
28
128
28
28
28
195
296
