Midland A-22075 Series User Manual

P/N: A-22075/6, Rev. 1.1
Page 30 of 45
7.0 Valve-Pressure Testing Procedure
If your company has an approved test procedure, follow it. If it does not, these procedures provide
essential guidelines in regards to pressure testing.
7.1 Initial Setup
7.1.1 Install the valve on the test fixture and alternately tighten down all of the nuts.
Figure 7-1 Affix Valve to Test Fixture
7.1.2 Seal drain holes of the valve body with putty, or a similar material.
Figure 7-2 Seal Drain Holes
Seal Drain Holes
