Midland A-22075 Series - Page 7

P/N: A-22075/6, Rev. 1.1
Page 7 of 45
Item
Qty.
Part Name
1
1
Top Guide with Insert
2
1
Valve Stem
3
1
Assembly Retainer
4
1
Valve Body
5
1
PRV Spring
6
1
Follower
7
1
Insert Locknut
8
1
O-ring (2-431)
9
1
O-ring (2-351)
10
2
Hex Nut
11
2
Hex-Head Cap Screw
12
2
Hex-Head Cap Screw
13
1
Name Plate
14
2
Drive Screw
15
1
Gasket
16
3
Wire-Seal Kit
17
1
Tube Assembly
Figure 1-5 A-22057-PI/A-22076-PI Valve Components
