OWNER’S MANUAL FOR THE F-12 (FRS)
http://www.midlandradio.com Page 9 of 13
ACTIVATING “PRIVACY” CODES
To activate “CTCSS” codes
Activating the “CTCSS” code will prevent you from hearing any conversation that is not using the
same
“CTCSS” code. This does not make your conversation private.
1. Press the “F” button twice to cause the icon “CTCSS” to be displayed in the upper left of the
display to flash.
2. Press and release the “UP” or “DOWN” buttons to select the “CTCSS” code you desire.
3. Press “ENTER” to store the code setting for that channel.
A code of “oF” means no code is programmed.
You must do this for each of the channels you want CTCSS codes on.
Activating the “CTCSS” code will prevent you from hearing any conversation that is not using
the same
“CTCSS” code. This does not make your conversation private.
4. If you wish to set another channel for CTCSS code, choose a different code than the ones
in use.
The following is a list of frequencies of the CTCSS codes. Different brands of radios may use a
different number code for the frequencies. For operation with other brands of radios the selected
CTCSS frequency must match.
01=67.0 Hz 11=97.4 Hz 21=136.5 Hz 31=192.8 Hz
02=71.9 Hz 12=100.0 Hz 22=141.3 Hz 32=203.5 Hz
03=74.4 Hz 13=103.5 Hz 23=146.2 Hz 33=210.7 Hz
04=77.0 Hz 14=107.2 Hz 24=151.4 Hz 34=218.1 Hz
05=79.7 Hz 15=110.9 Hz 25=156.7 Hz 35=225.7 Hz
06=82.5 Hz 16=114.8 Hz 26=162.2 Hz 36=233.6 Hz
07=85.4 Hz 17=118.8 Hz 27=167.9 Hz 37=241.8 Hz
08=88.5 Hz 18=123.0 Hz 28=173.8 Hz 38=250.3 Hz
09=91.5 Hz 19=127.3 Hz 29=179.9 Hz oF =OFF
10=94.8 Hz 20=131.8 Hz 30=186.2 Hz
RESETTING THE RADIO
If the radio stops responding to button presses or otherwise does not function properly in some
cases the radio can be reset to restore normal operation.
To reset the radio: With the radio off, press and hold the “F” button and turn the radio on.
Release the “F” button when the radio powers up. (see turning the radio on)
