Frequency range 446.00625- 446.09375 MHz (PMR446)
Working temperature -20°+50°
Operating voltage 7.4V
Operate mode Simplex
Dimensions 100mm×58mm×33mm (without Antenna)
Weight 203g (Battery pack included)
Antenna impedance 50Ω
Duty cycle 5/5/90%
Frequency stability ±2.5PPM
Output power ≤500mWERD
Max frequency deviation ≤2,5KHz
Audio distortion ≤3%
Adjacent channel power < 60 dB
Spurious radiation Within European legal terms
Occupied bandwidth Within European legal terms
RF sensibility ＜0.2UV@20 dB SINAD
Audio distortion ≤3%
Audio response 300Hz ÷ 3KHz
Adjacent channel selectivity Within European legal terms
Intermodulation rejection Within European legal terms
Spurious response Within European legal terms
Blocking Within European legal terms
Hereby, CTE International declares that this is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of
Declaration of Conformity can be found at:
