10 | Midland G15 instruction guide
Technical specifications
General
Frequency range 446.00625- 446.09375 MHz (PMR446)
Working temperature -20°/+55° C
Operating voltage 7.4V
Operate mode Simplex
Dimensions 105mm×50mm×32mm (without Antenna)
Weight 227g (Battery pack included)
Antenna impedance 50Ω
Duty cycle 5/5/90%
Transmitter
Frequency stability ±2.5PPM
Output power ≤500mW ERP
Max frequency deviation ≤2,5KHz
Audio distortion ≤3%
Adjacent channel power < 60 dB
Spurious radiation Within European legal terms
Occupied bandwidth Within European legal terms
Receiver
RF sensibility <0.2UV@20 dB SINAD
Audio distortion ≤3%
Audio response 300Hz ÷ 3KHz
Adjacent channel selectivity Within European legal terms
Intermodulation rejection Within European legal terms
Spurious response Within European legal terms
Blocking Within European legal terms
Hereby, CTE International declares that this G15 is in compliance with the es-
sential requirements and other relevant provisions of Directive 1999/5/EC.
WARNING: Direct plug-in ac/dc power supply must be used for disconnecting the tran-
sceiver from the mains; the desktop charger must be positioned close to the unit and
easily accessible.
