Page 7 www.midlandradio.com
BA
TTERY INSTALLATION
Your LXT110/80 Series radio operates with 3 AAA alkaline batteries or
a NiMH rechargeable battery. The belt clip should be removed (see
below) to ease installation or removal of the batteries.
To install the batteries:
1. With the back of the radio facing you, remove the belt clip (see
diagram below) for easy access, then remove the Battery Cover
by pressing down on the top center and sliding it down from the
radio.
2. Insert 3 AAA batteries observing the polarity as shown on the
Battery Compartment. Installing the batteries incorrectly will prevent
the unit from operating or may damage the unit.
3. Return the Battery Cover by sliding it up on the radio. Replace the
belt clip, making sure it locks into place.
Model LXT110/80
INSTALLING THE BELT CLIP
To install the BELT CLIP, slide the clip up into the slot on the back of
the radio until the BELT CLIP LATCH clicks. To remove the BELT
CLIP, lift the LOCK TAB up, then gently pull the belt clip down toward
the bottom of the radio.
