Midmark 626 - Remove PCB Shelf Assembly

2
© 2018 Midmark Corp. | 60 Vista Drive Versailles, OH 45380 USA | 1-800-643-6275 | 1-937-526-3662 |
PCB Shelf
Assembly
MA10563i
Step 3: Remove PCB Shelf Assembly
A) Remove the four screws holding the PCB Shelf Assembly
B) Disconnect wire harnesses from PC Boards located on the
PCB Shelf Assembly.
C) Remove the PCB Shelf Assembly.
