Appendix A
Preva
116
Appendix A
Assembly Instructions for DC Mobile Unit
Tools Required
3/8” square drive hex key 10 mm
3/8” square drive hex key x 6-inch extension
3/8” square drive ratchet
No. 1 Phillips screwdriver
7 mm nut driver
Small flat-blade screwdriver
4 mm hex key
5 mm hex key
FIGURE 113
1. Open the box from the top side.
FIGURE 114
2. Remove all transportation screws from the base of the crate ( Qty. 10)
