System Configuration
Preva
67
Changing the Cone Size
Selecting SET CONFIG from the Configuration menu, Figure 52, displays the
Set Configuration menu, Figure 53, with options to change the cone size. The
Preva Dental X-ray System is preset for use with the standard supplied 8” [20
cm] Cone. The 12” [30 cm] Cone (30-A2033) is available. Using the longer
Cone requires longer exposure times, which the Preva automatically selects
when you change the Cone size in the Set Configuration menu.
Using a 12 inch
[30 CM] Cone
1. From the Main System Configuration menu, Figure 49, select
CONFIGURE UNIT. You will see the Configuration menu shown in Figure
52.
2. Select SET CONFIG. You will see the Set Configuration menu, shown in
Figure 53.
3. From the Set Configuration menu, use the up and down arrows to highlight
the 12” CONE SIZE.
4. Press the right arrow button to select the 12” Cone. The display warns you
that selecting the 12” Cone will override custom presets with the default
factory settings for the 12” Cone.
5. Using the up arrow, select YES to install presets for the 12” Cone.
Figure 53
Set Configuration
Menu
