Midmark Preva - Preva Tubehead Removal Instructions

Maintenance
Preva
91
Figure 70
3. Install the cone in the replacement tubehead.
Figure 71
4. Remove the two Allen head screws from the yoke and remove the yoke
cover.
Figure 72
5. Unplug the black and white connector.
Figure 73
6. Remove the two Allen head screws that secure the two ground wires to the
yoke. Take note of the position of each ground wire.
3mm screws
(
2x
)
3mm screws
(
2x
)
