DWDWU0HWKRGV
To perform a particular test or function, the Battery Diagnostic
Station requires dierent types of information. This means
that the methods you use to enter information will change
depending on the type of information requested. The six types
of entry methods are described below.
Typically, the soft key below the right half of the screen
conrms your choice, although the command above it may
vary. (Examples: SELECT, NEXT, and SAVE.) In a similar fashion,
the soft key below the left half of the returns you to the
previous screen or enables you to print results, although the
word above it may also vary. (Examples: BACK and PRINT.)
0HXLFRV
A menu icon is a graphical
representation of a function
you can select, such as the
Diagnostic Icon in the Main
Menu. To select an icon, use the
LEFT or RIGHT ARROW key to
highlight it. Highlighting changes the icon to a white picture
on a black background. To conrm your selection, press the
appropriate soft key.
2SWLR%XWWRV
Some lists have option buttons
before each item. To select an
item, use the UP ( ) or DOWN
( ) ARROW keys to move the
dot to the button next to the
item. To conrm your selection,
press the appropriate soft key.
You can also use the alphanumeric keypad to enter the
number preceding the option button of your choice. No
additional keypress is needed to proceed.
6FUROOL/LVWV
Scrolling lists contain items that
extend above and below the
screen. The rst number above
the right soft key indicates
the position in the list of the
highlighted item. The second
number above the right soft key indicates the number of items
in the list.
To select an item, the UP ( ) or DOWN ( ) ARROW key to
highlight the item, and press the appropriate soft key.
To move the highlight bar up four lines at a time, press the
LEFT ( ) ARROW. To move the highlight bar down four lines at
a time, press the RIGHT ( ) ARROW key.
$OSKDXPHULF(WU
Some selections require you to
use the alphanumeric keypad.
These “user-dened” selections
have a blinking horizontal line
(cursor) to the right of the last
character.
Use the UP or DOWN ARROW keys to highlight a line for
editing. Display the character, symbol, or number you want
by rapidly pressing its key as many times as needed. If you
pause, the cursor moves to the right. To backspace, press the
LEFT ARROW key. Use the RIGHT ARROW key to add a space.
Use the UP/DOWN ARROW keys to highlight a line for editing.
When nished, press the appropriate soft key to save your
settings.
9DOXH%RHV
Value boxes contain items
that extend above and below
the selection box that contain
them. To indicate that there are
more values, the symbols
appear to the right of the box.
To select, use the UP or DOWN ARROW key to scroll to the
value, or use the keypad to enter the value directly, and press
the appropriate soft key. In the illustration the left directional
arrow indicates that you can press the LEFT ARROW key to
clear all or part of the entry.)
