Installation notes
33
Seal between the CombiSet
and the worktop
Do not use sealant between the
CombiSet and the worktop. This
could result in damage to the
CombiSet or the worktop if the
CombiSet ever needs to be removed
for servicing.
The sealing strip under the edge of
the top part of the appliance
provides a sufficient seal for the
worktop.
Tiled worktop
Grout lines and the hatched area un-
derneath the CombiSet frame must be
smooth and even. If they are not the
CombiSet will not sit flush with the
worktop and the sealing strip under-
neath the top part of the appliance will
not provide a good seal between the
appliance and the worktop.
