Installation – surface-mounted
If the worktop is more than 24mm
deep, it must be cut out underneath
on the building-in side on the right or
left-hand side.
a
Worktop
b
Maximum 24mm
c
12 mm
Securing the bracket
1 bracket (supplied with the spacer bar)
must be secured centrally to the right or
left-hand side of the cut-out.
Wooden worktops
 Fit the bracket so that it sits flush
with the top edge of the worktop cut-
out.
 Secure the bracket with the
3.5x25mm wood screws supplied.
Granite and marble worktops
You will need heavy-duty double-
sided tape (not supplied) to secure the
bracket.
 Stick the tape along the top edge of
the worktop cut-out.
 Fit the bracket so that it sits flush
with the top edge of the worktop cut-
out.
 Press the bracket firmly into position.
