Miele DA 1260 User Manual

Installation
27
Distance between cooktop and ventilation hood (S)
Provided a larger distance is not given by the manufacturer of the cooktop,
follow the minimum safety distances between a cooktop and the bottom of the
hood.
Please also observe the information contained in the "IMPORTANT SAFETY
INSTRUCTIONS" section.
Minimum distance S
Cooking appliance Miele
appliance
Non-Miele
appliance
Electric Cooktops 24" (610 mm)
Electric Barbeques and Fryers 26" (660 mm)
Multiburner Gas Cooktops
≤ 43,000 BTU/hr (12.6kW),
no burner > 15,000 BTU/hr (4.5 kW).
26" (660 mm) 30" (760 mm)
Multiburner Gas Cooktops
≤ 73,800 BTU/hr (21.6kW),
no burner > 16,500 BTU/hr (4.8 kW)
30" (760 mm)
Multiburner Gas Cooktops
> 73,800 BTU/hr (21.6kW),
or one of the burners > 16,500 BTU/hr (4.8 kW)
Not possible
Single Burner Gas Cooktops
≤ 20,500 BTU/hr (6 kW)
26" (660 mm) 30" (760 mm)
Single Burner Gas Cooktops
> 20,500 BTU/hr (6 kW)
≤ 27,600 BTU/hr (8.1 kW)
30" (760 mm)
Single Burner Gas Cooktops
> 27,600 BTU/hr (8.1 kW)
Not possible

Miele DA 1260 Specifications

General

Noise level	64 dB
Intensive speed	Yes
Number of speeds	3
Type of extraction	Ducted/Recirculating
Maximum extraction power	545 m³/h
Noise level (boost mode)	74 dB
Lighting efficiency class	A
Minimum distance from gas hob	650 mm
Fluid dynamic efficiency class	D
Minimum distance from electric hob	450 mm
Type	Built-under
Cord length	1.5 m
Product color	Brown
Built-in display	No
Current	10 A
Motor power	- W
Connected load	240 W
AC input voltage	230 V
AC input frequency	50 Hz
Annual energy consumption	91.6 kWh
Bulb type	LED
Bulb power	3 W
Illuminance	330 lx
Number of bulbs	2 bulb(s)
Number of filters	2 pc(s)
Grease filter type	Stainless steel

Weight and Dimensions

Depth	500 mm
Width	598 mm
Height	125 mm
Weight	11200 g
