DA 206, DA 216, DA 217:
Secure the vapour guide with two 4 x
30 mm screws and two 4.3 mm
washers.
DA 209, DA 219:
Secure the vapour guide with two 4 x
30 mm screws and two 4.3 mm
washers.
Put the lighting tubes and grease fil-
ters back in place.
Motor unit
(only for appliances with an integrated fan)
First loosely screw the two stiff nuts
on the threaded bolts of retaining
plate A. Leave enough space to be
able to hang the motor on afterwards.
Mount the motor unit into the hooks
of retaining plate A and slide down
behind the nuts.
Tighten the nuts.
Installation
26
