Do not install this exhaust hood over
cooktops burning solid fuel.
When installing the hood, make sure
that the following minimum dis
-
tance (S) between the top of a Miele
cooking surface and the bottom of
the hood is:
- 22" (55 cm) above electric cooktops
- 26" (65 cm) above gas cooktops
- 26" (65 cm) above an open grill
For non-Miele cooking appliances
maintain the safety distances recom
-
mended by the cooktop manufac-
turer in their installation and operat-
ing instructions.
If there is more than one appliance
beneath the hood and they have dif-
ferent minimum safety distances al-
ways select the greater distance.
See "Warning and Safety instruc-
tions" for further information.
26" (65 cm) is recommended for all in
-
stallations to allow for optimum work
space under the hood.
Read the entire installation procedures
and determine height S before begin
-
ning the installation.
If the hood is fitted flush to the ceiling
make sure that the remaining distance
to the ceiling is not greater or less than
appliance height H.
Standard unit height H:
DA 229-2. . . . . . . . . . . . . 29
1
/
8
" - 42
1
/
8
"
. . . . . . . . . . . . . . . . . . (740 - 1070 mm)
To fit the chimney, distance A between
the top of the chimney and the ceiling
must be at least
7
/
8
" (20 mm).
Cut out area in wall or ceiling for
entrance of 6" (150 mm)
ductwork or 5" (125 mm)
ductwork with a reducing collar.
If the standard unit height H is not suit
-
able to the kitchen’s ceiling height, lon
-
ger optional chimney extensions are
available from your Miele dealer or
Miele’s Technical Service Department.
Extension available for this model:
DATK 229-650. . . . . . . . . 42
1
/
8
" - 53
3
/
4
"
. . . . . . . . . . . . . . . 1070 mm - 1350 mm
Appliance dimensions
