Attaching the chimney
^ Remove the protective foil from the
chimney.
^ Pull the chimney apart slightly
and
slide it over the chimney extension.
Do this carefully to prevent scratch-
ing the two pieces.
^
Slide the chimney down about
3
/
4
"
(2 cm) into the canopy.
^
Align and adjust the chimney.
^
Remove the protective shields.
^
Secure the chimney to retaning plate
A on both sides with two 3.9 x 7.5
mm screws.
^
Remove the protective foil from the
canopy.
If the chimney is not tall enough an
optional chimney extension can be
ordered. See "Appliance dimen-
sions".
^
Before using the appliance remove
the grease filter and remove the pro
-
tective foil from the filter frame. Re
-
turn the filter.
Installation
35
