Miele DA 3496 - Appliance Dimensions and Materials

Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
27
a
1 vent connection
for exhaust ducting 150mm
b
1 non-return flap
for fitting into the exhaust socket on
the motor unit (not needed for
recirculation mode)
c
2 brackets
for securing the cooker hood into
the wall unit
d
1 spacer strip
for concealing the gap between the
rear of the appliance and the wall
e
DML400 installation kit for fitting
a drop-down front panel
not supplied but available as an
optional accessory; contains hinging
and screws for fitting a front panel to
match kitchen furniture
f
Conversion kit for recirculation
mode
not supplied but available as an
optional accessory, see “Technical
data”; contains an exhaust grille and
aluminium hose with hose clips
14 screws 4x15mm
for securing the cooker hood into the
wall unit
8 screws M4x12mm
for securing the cooker hood to the
brackets
4 of the screws can be used instead of
the plastic rivets to secure the spacer
strip
4 plastic rivets
for securing the spacer strip
