Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
35
Secure the cooker hood to the
brackets from below using two
screws on each side.
Pull out the deflector plate and
remove the protective film between
the deflector plate and the casing.
Secure the cooker hood to the floor
of the housing unit from below using
4 screws (6 screws are required for a
90cm wide cooker hood).
To avoid damaging the deflector
plate when it is pulled out, care
should be taken to screw the fixing
screws in straight and to ensure that
the screwheads are countersunk.
Secure the spacer strip to the back of
the appliance from behind using 4
plastic rivets as shown.
