The Miele DSM 400 control module can
be used to combine the rangehood with
other components.
It enables the following:
Potential free connection
This is used for controlling another
appliance with the help of the
rangehood's On/Off button s.
The potential free contact of the
DSM 400 a can be installed in an
...EXT model, for instance, which is
connected to a central extraction
system.
The contact can be used to activate a
motorised shut-off flap b which is
installed before the central extraction
system c.
The components of the central
extraction system are not supplied as
standard by Miele.
If in any doubt, the advice of a
competent builder must be sought.
Connection to a light switch
The control module can be used to
switch on the rangehood lighting via a
light switch in the house.
Installation
The tower needs to be removed before
the control module can be fitted to the
motor unit.
Operation with Control module DSM 400
30
