Miele DAD 4940 User Manual

Before using for the first time
19
For the registration, you will need:
1. Your WiFi network password
2. Your cooker hood password
The password for your cooker hood
consists of the last 9 digits of the serial
number. This can be found on the
appliance's data plate.
The data plate can be found on the
front of the housing.
 Follow the instructions to start
registering the appliance in the app.
If requested to activate WiFi on the
cooker hood, proceed as follows:
 With the deflector plate retracted,
touch the On/Off switch.
All symbols light up with reduced
brightness.
 Press and hold the run-on option
control until the grease filter
and charcoal filtersymbols light
up.
 Touch 2.
The deflector plate extends.
2will light up constantly, 3will flash.
The cooker hood will be ready for
connection in the next 2minutes.
 Follow the instructions in the app.
When successfully connected, 2and
3will light up constantly.
 Quit connection mode on the cooker
hood by touching the run-on option
control.
The cooker hood can now be operated
via the app.

Miele DAD 4940 Specifications

General

Type	Downdraft
Timer	Yes
Cord length	1.5 m
Control type	Buttons, Wireless
Product color	Black
Built-in display	-
Exhaust connection diameter	150 mm
Noise level	62 dB
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	44 dB
Maximum extraction power	440 m³/h
Noise level (medium speed)	57 dB
Maximum recirculating power	415 m³/h
Noise level (intensive speed)	70 dB
Fluid dynamic efficiency class	A
Noise level (recirculation mode)	69 dB
Grease filtering efficiency class	B
Current	10 A
Connected load	250 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	41.6 kWh
Grease filter type	Metal
Bulb type	LED
Bulb power	11.2 W
Illuminance	400 lx
Number of bulbs	1 bulb(s)

Weight and Dimensions

Depth	170 mm
Width	936 mm
Weight	34000 g
