Before using for the first time
22
Setting up Con@ctivity
Con@ctivity is the direct communication
system between an electric Miele hob
and a Miele cooker hood. It enables the
cooker hood to operate automatically
depending on the operational state of a
Miele hob with onset controls.
- When the hob is switched on, the
cooker hood lighting comes on
automatically and then after a short
time the fan also comes on.
- The cooker hood selects the power
level automatically during cooking.
The power level selected by the
cooker hood depends on the number
of cooking zones being used and
their power levels.
- After switching the hob off the fan
and the hob lighting will switch off
automatically after a specified period
of time.
See “Operation” for detailed information
about this function.
Con@ctivity via the home WiFi
network (Con@ctivity 3.0)
Prerequisite:
- Home WiFi network
- WiFi-enabled Miele hob
 Connect the cooker hood and hob to
your home WiFi network (see “Setting
up Miele@home”).
The Con@ctivity function will be
activated automatically.

Miele DAD 4940 Specifications

General

Type	Downdraft
Timer	Yes
Cord length	1.5 m
Control type	Buttons, Wireless
Product color	Black
Built-in display	-
Exhaust connection diameter	150 mm
Noise level	62 dB
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	44 dB
Maximum extraction power	440 m³/h
Noise level (medium speed)	57 dB
Maximum recirculating power	415 m³/h
Noise level (intensive speed)	70 dB
Fluid dynamic efficiency class	A
Noise level (recirculation mode)	69 dB
Grease filtering efficiency class	B
Current	10 A
Connected load	250 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	41.6 kWh
Grease filter type	Metal
Bulb type	LED
Bulb power	11.2 W
Illuminance	400 lx
Number of bulbs	1 bulb(s)

Weight and Dimensions

Depth	170 mm
Width	936 mm
Weight	34000 g
