Installation
47
Building in the drawer
Risk of injury!
The drawer is heavy and will tip for-
wards when open.
Installation must be carried out by
two people.
Keep the drawer closed until the
anti-tipping mechanism supplied has
been fitted to the side walls of the
housing unit.
Check that the base that the drawer
will sit on is clean and level (use a
spirit level). This is important for the
appliance to function correctly.
Fitting the anti-tipping mechanism
Measure the distance to the right and
left hand side walls of the housing
(see illustration).
Mark the uppermost position in the
long slot of the anti-tipping mechan-
ism. Make sure that the anti-tip-
ping mechanism is flush with the
base of the housing unit.
Secure the anti-tipping mechanism to
the right and left hand side walls of
the housing unit with the 4screws
supplied (4x16mm).
