Technical Information
100
G 5xxx
Warning!
Installation aids that contain silicone, e.g., silicone grease, are not suitable
for use in dishwashers because of the damage they can cause.
If, e.g., hoses or seals are treated with silicone in order to facilitate
installation, this could jam the circulation pump. Furthermore, ingredients in
silicone grease can evaporate and damage electrical components such as
heater relays.
4.13 Circulation Pump Removal
Warning!
MPPW circulation pump only:
In the open motor housing, there is an electronic module circuit board (PCB)
which must be protected from moisture and water ingress in order to avoid
short circuits.
Before starting service work, make sure that there is no residual water in the
machine.
In order to avoid damage from splashes, the drip pan must not be
dehumidified with compressed air.
1. Uninstall the appliance.
2. Disconnect the appliance from the power supply.
3. Remove the screw securing the pump mounting bracket to the rear panel.
4. Tip the appliance onto its back.
5. Remove the drip pan. See Section 010-4.2.
6. Disconnect all electrical connections from the pump.
7. Place towels or rags underneath the circulation pump’s hose connections
to collect any residual water.
8. Disconnect all hoses from the circulation pump.
9. Remove the circulation pump from the appliance and take off the
mounting bracket.
Note:
When installing the circulation pump, it is important to first install the sump
seal on the pump. Then slide the circulation pump with seal into the sump
housing and secure the pump.
Important!
During reassembly of the circulation pump ensure:
1. A new seal is installed
2. The seal is seated correctly in the pump housing cap
3. The pump housing cap is evenly seated
4. The cap retaining screws are secure
5. The fastening clips are pressed over the retaining lugs
