Now adjust the feet until the seal on
the top of the dishwasher is right up
against the underside of the
worktop, to which it will be screwed
later. Ensure that the dishwasher
stands level.
Rear screw feet
^ Use a TORX T20 screwdriver to
adjust the rear screw feet
to the
required height.
Higher = turn clockwise
Lower = turn anti-clockwise
Several turns are needed to adjust
1 mm in height.
Front screw feet
^ Adjust the front screw feet
manually
or with a flat blade screwdriver.
Installing integrated "i" Dishwashers
12
