7.Adjusting the plinth return
The plinth return on a "U" model
dishwasher can be adjusted between
35 and 100 mm in 2.5 mm increments.
^
Push the spring clips on either side of
the dishwasher outwards and push
the brackets right in.
On dishwashers G 636 - G 698
G 975
The fixing brackets face inwards.
On dishwashers G 836 - G 898
The fixing brackets face outwards.
Installing built-under "U" model dishwashers
33
