Technical Information
56
G 600/G 800
Figure 5-16: Hinge Removal
5.14 Door Tension Adjustment
1. Open the door.
2. Locate the spring adjustment screw on the left side of the dishwasher at the top
front edge as shown in Figure 5-17.
3. Use a T-20 screwdriver to adjust the screw as follows:
 Clockwise – Tighten.
 Counterclockwise – Loosen.
Figure 5-17: Door Tension Adjustment Screw
4. Adjust the door as follows:
 With the door opened to a 45° position, it should remain stationary (does not
continue to open OR close on its own tension).
 Repeat Step 3 as needed.
Warning!
Replacement of door tension springs and/or the door panel requires readjustment of
the door tension.
5.15 Top Spray Arm Removal
1. Open the door.
