The door panel is attached to the
dishwasher using the mounting bracket
that comes secured to the front of the
unit.
To remove the bracket:
^ Open the door 2 - 4" (5 - 10 cm).
^ Loosen the bracket retaining screw
(black arrow) located on each side of
the machine door.
^
Pull the bracket up until the upper
section of the bracket disengages
from the locator pins, then remove
the bracket.
Installation
18
