Aligning the appliance
^ Align the appliance with the custom
front.
The height-adjustable feet at the front
and rear can all be adjusted from the
front:
– Front feet:
Adjust with a rachet 5/16" (8 mm) c.
– Rear feet:
Adjust with a (cordless) screwdriver
and/or a rachet 5/16" (8 mm) for fine
adjustment d.
Important!
When unscrewing the
height-adjustable feet, proceed
gradually, alternating between left
and right.
^ Unscrew the height-adjustable feet
until the mark on the base has
reached the indicated guide
dimension 1 1/4" (32 mm). The guide
dimension of 1 1/4" (32 mm) is
related to a niche height of 84"
(2134 mm).
Important!
The height-adjustable feet can only
be unscrewed as far as the mark 2
3/16" (62 mm) on the base (max.
niche height of 85 3/16" (2164 mm).
^ Align the custom doors with a level.
^ If using a wooden beam as an
alternative anti-tip device, rotate the
appliance all the way toward the
wooden beam.
Note:
– The adjustment of the rear feet is
aided if the appliance is lifted at the
rear (tipped forward slightly).
Installing the appliance
72
