Installation of appliance on wall with additional niche cladding
Hob with frame/bevel edge Flush fit hob
a Masonry
b Niche cladding
c Upstand
d Worktop
e Worktop cut-out
f 50 mm minimum distance between niche cladding and the worktop cut-out.
This distance is only necessary for niche cladding made of wood or any other
combustible material. For non-combustible materials (metal, ceramic tiles or
similar), this dimension can be reduced by the thickness of the niche cladding
material. The materials can warp or distort when subjected to high tempera
-
tures.
Safety instructions
5
g
min. 50
b
c
f
d
e
g
min. 50
b
c
f
d
e
e
