Flush-fitted cooktops
63
Installation
Granite and marble worktops
a
Worktop
b
Cooktop
c
Gap
As the ceramic glass and the worktop
cut-out have a certain dimensional
tolerance, the size of the gap can
vary (min.1mm).
Solid wood / tiled / glass worktops
a
Worktop
b
Cooktop
c
Gap
d
Wooden frame 13 mm (not supplied
with appliance)
As the ceramic glass and the worktop
cut-out have a certain dimensional
tolerance, the size of the gap can
vary (min.1mm).
