The exact positions of the spring
clamps, and the safety brackets for
hobs with bevelled edges, are shown
in the building-in dimensions for the
particular hob.
Hobs with bevelled edges:
The sealing strip will ensure that the
hob sits securely in the cut-out. Any
gap between the frame and worktop
will reduce with time.
^
Make the worktop cut-out according
to the dimensions given in the
building-in dimensions. Remember to
maintain the minimum safety
distances (see "Safety instructions
for installation").
Worktops made of wood
^
Seal the cut surfaces with a suitable
heat-resistant sealant to avoid
swelling caused by moisture.
Make sure that the sealant does not
come into contact with the top of the
worktop.
^
Depending on model, place spring
clamps a (supplied) on the upper
edge of the cut-out or for hobs with
bevelled edges, safety brackets b
(supplied) flush with the upper edge
of the cut-out.
^
Secure the spring clamps a or
safety brackets b using the
3.5 x 25 mm wood screws supplied.
Installation
60
