Miele KMR 1124-3 LP EDST/CLST

Dimensional drawings
*INSTALLATION*
KMR 1124-3
Position Dimensions Description
 min. 30"
(762mm)
Niche width
 37" (940mm) Minimum distance between the top
of the cooking area and the bottom
of an unprotected combustible
surface.
30" (762mm) Minimum distance between the top
of the cooking area and the bottom
of the Miele Range Hood (DAR
model with DRxB XL blower).
For all other hoods please consult the manufacturer's specifications
for required distances.
Please observe safe distances to rear combustible surfaces of 12" (305mm) clearance. For
zero clearance installation the Miele Backguards will satisfy the required distance to
combustible surfaces. The Miele Backguard is available in 12" (305mm) or 20" (508mm)
heights.
