Technical Information
43
MasterChef Ovens
Caution:
Ensure that the wire does not contact the coated surfaced, or irreversible
damages to the surface can result.
3. Pull the door latch (Figure 5-18, Item 2) by moving the wire horizontally to
the right.
Figure 5-18: Door Latch Manual Release (“P” Models Only)
5.18 Upper Door Lock Motor and Switch Removal (P-Model
Double Ovens Only)
1. Remove the oven for service (Section 5.5).
2. Remove the upper rear panel (Section 5.11).
3. Unplug the electrical connections to the door lock motor (Figure 5-19, Item 3).
4. Remove the screws securing the door lock motor (Figure 5-19, Item 2).
Figure 5-19: Door Lock Motor Assembly
5. Loosen the Bowden cable retaining nut (Figure 5-20, Item 1).
6. Remove the Bowden cable from the mounting bracket.
Note:
When the cable tension is released, the oven door locks.

Miele MasterChef H 395 BP Specifications

General

Power consumption	3.6 kW
Installation type	Built-in
Oven capacity	71 liters
Display	Digital
Self-cleaning	Pyrolytic
Width	594 mm
Oven volume	71 liters
Display Type	Digital
Capacity	71 liters
Frequency	50 Hz
Cleaning	Pyrolytic
