Installation
*INSTALLATION*
37
 Adjust the front feet with a ratchet (at-
tachment: 5/16” (8mm) socket) or a
TX20 screwdriver .
Tip: Proceed carefully when adjusting
the feet, alternating between the left
and right feet.
 Place a level across the installation
aids  on the appliance door to
check the refrigeration appliance’s
alignment.
 Unscrew the feet and on both
sides at least until the marking on the
toe-kick is aligned with the required
1 1/4” (32mm) on the spacer . The
standard dimension of 1 1/4” (32mm)
relates to a niche height of
84” (2,134mm).
It is important to adjust the feet to a
height of at least 1 1/4” (32mm) so
that the ventilation of the refrigeration
appliance via the toe-kick functions
correctly.
 Risk of damage if the feet are
adjusted too much.
The rear adjustable feet can be dam-
aged.
Unscrew the feet only until the
marking on the toe-kick is aligned to
a maximum of 2 7/16” (62mm) (max.
niche height of 85 3/16” (2,164mm)).
